Quick Details

  • Condition: New
  • Type: Wheel Tractor
  • By wheel: 4WD
  • Usage: Farm Tractor
  • Drive Type: Other
  • Certificate: ISO9001,ISO2000
  • Brand Name: YTO
  • Model Number: YTO-X904
  • Place of Origin: Henan, China (Mainland)
  • After-sales Service Provided: Engineers available to service machinery overseas
  • Product name: Low price YTO-X904 4WD Cheap farm tractor for sale philippines
  • Hp: 90
  • Drive type: 4WD
  • Engine: YTO
  • Number of speed gears: 12F+12R
  • Wheel tyres (front/rear): 13.6-24/16.9-34
  • Steering: Hrdraulic steering
  • Hydraulic output valve: 2-Way or 3 ways
  • Dimension LxWxH (mm): 4350x2000x2765
  • Optional: A/C, Air brake, Front loader, backhoe, plough, etc

Packaging & Delivery

Packaging Details international export package, 3 sets in one 40HC
Delivery Time Within 20 days

Chinese Best tractor YTO tractor sale in Australia

Company Information



Henan Dexing Machinery Equipment Co.,LTD is a professional farm machinery supplier.


 Contact Anne for Professional YTO tractor 90hp YTO-X904 :






Product Description



 Features of Low price YTO-X904 4WD Cheap farm tractor

The diesel engine .which is manufactured using advanced British technology. Delivers large torque, high fuel efficiency and low emission. PERKINS engine is also optional.

The transmission system is made on the basis of Italian technology. The top speed can be more than 35km/h

The full hydraulic steering system is utilized for easy operation.

High safety is ensured due to the use of the wet disc brake.

Optional new cab is not only elegant but also can be equipped with an air conditioning system so as to lifer the driver a high level of comfort,

In addition to built-in master cylinder, two auxiliary cylinders can also be used, resulting in increased lift force (30kn)

Our wheel loader adopts double action clutch. German LUK clutch is available for your choice.

Specifications of YTO tractor 90hp

Model

YTO-X904

Tractor

Type

4×4

Overall dimensions(L×W×H)(mm)

4350×2000×2765

Wheelbase(mm)

2314

Min ground clearance(mm)

440

Min .operating mass(with safety stand)(kg)

3920

Tire spec,   front/rear

13.6-24/16.9-34

Wheel tread, front/rear

1562~2000/

1520~2120

Steering

Full hydraulic

Brake

Oil immersed, disk type

Diesel engine

Model

LR4M5-23

Type

Four cylinder ,vertical, water cooled ,four stroke, direct injection   combustion

Displacement(L)

5.13

Rated. power/speed (kw)(r/min)

66.5/2300

Max .torque(N.M)speed(r/min)

325/1600-1800

Bore ×stroke(mm)

110×135

Transmission

Gear shift, forward/backward

12/4

Speed range(km/h)forward/backward

1.61~26.57/4.28~12.85

PTO   power(kw)

55

PTO   rotation speed(r/min)

540/720   or 540/1000

Clutch

11-inch,dry,double   action

Im plement

Three-point linkage category

Three-point linkage category II

Tilling depth control mode

Combined draft, position control and floating control

Lifting force(kn)

16

Options

OECD.anti-turnover   bar

OECD   certified anti-turnover bar or anti-turnover bar with awning

Transmission with shuttle-type gear

12+12

Transmission with creeper gear

24+8

Hydraulic output

2 or 3   group
